Developing a Cross-Platform PDF-to-SVG/PNG Wrapper for .NET

PDF->SVG/PNG: fusing Poppler’s battle-tested PDF engine with Cairo’s SVG output surface, then wraps the native glue in a tidy C# API via [DllImport]
C#
·
15 min
·
2025/06/17

PDF->SVG/PNG: fusing Poppler’s battle-tested PDF engine with Cairo’s SVG output surface, then wraps the native glue in a tidy C# API via [DllImport]

Building a Cross-Platform PDF-to-SVG Bridge for .NET

The business problem

A few weeks ago a customer asked for PDF pages to appear inside a generated DOCX report.

  • Converting each page to raster images (PNG/JPEG) ballooned the file size and slowed down the pipeline.

  • Embedding raw PDF was out - the Word rendering engine would not display it reliably.

Goal: “If a page can be expressed as scalable vector graphics, embed it as SVG; otherwise fall back to a single PNG bitmap.”

That single sentence drove the rest of the journey.

Designing the native engine

Choosing the tools

  • Poppler - mature PDF parser / renderer.

  • Cairo - can paint to many back-ends, including an SVG and PNG surfaces.

Together they let us walk the display list that a PDF page contains and stream the final drawing instructions into memory - no temp files required.

A minimal C API

The C++ core is wrapped in five plain-C entry points so any language with FFI can bind to it:

/* pdf2svg.h - simplified */
void* pdf_open_doc(const unsigned char* bytes, int len, int* out_page_count);
void  pdf_close_doc(void* doc);

unsigned char* pdf_get_page_data(
        void* doc, int page_num,
        bool force_to_png,          /* fallback switch           */
        int  dpi,                   /* raster DPI for PNG pages  */
        int* out_len,
        bool* out_is_svg            /* tells caller PNG vs SVG   */
);

void pdf_release_buffer(unsigned char* buffer);

Under the hood pdf_get_page_data looks at Poppler’s text mapping to decide whether the page is vector-friendly. If it’s an “image only” page (e.g., a scanned sheet), Cairo renders it onto a PNG surface at the requested DPI.

Implementation of the - pdf_get_page_data

unsigned char*
pdf_get_page_data(void*   doc_handle,
       int     page_num,
       bool    force_to_png,
       int     dpi,
       int*    out_len,
       bool*   out_is_svg)
{
    auto* ctx = static_cast<PdfDoc*>(doc_handle);
    PopplerPage* page = poppler_document_get_page(ctx->doc, page_num);
    if (!page) {
        *out_len    = 0;
        *out_is_svg = false;
        return nullptr;
    }

    double w, h;
    poppler_page_get_size(page, &w, &h);

    bool has_text = false;
    bool image_only = false;

    if (!force_to_png) {
        char* txt = poppler_page_get_text(page);
        has_text = (txt && *txt != '\0');
        g_free(txt);

        GList* images = poppler_page_get_image_mapping(page);
        const double tol = 0.5;

        for (GList* iter = images; iter; iter = iter->next) {
            auto* m = static_cast<PopplerImageMapping*>(iter->data);
            if (fabs(m->area.x1) < tol &&
                fabs(m->area.y1) < tol &&
                fabs(m->area.x2 - w) < tol &&
                fabs(m->area.y2 - h) < tol)
            {
                image_only = true;
                break;
            }
        }
        poppler_page_free_image_mapping(images);
    } else {
        image_only = true;
    }

    std::vector<unsigned char> buf;
    if (image_only && !has_text) {
        if (dpi <= 0)
            dpi = 72;

        double scale      = dpi / 72.0;
        int    width_px   = static_cast<int>(std::ceil(w * scale));
        int    height_px  = static_cast<int>(std::ceil(h * scale));

        // Rasterize to PNG
        cairo_surface_t* img_surf = cairo_image_surface_create(
            CAIRO_FORMAT_ARGB32,
            width_px,
            height_px);

        cairo_t* img_cr = cairo_create(img_surf);

        cairo_scale(img_cr, scale, scale);

        poppler_page_render(page, img_cr);

        cairo_destroy(img_cr);

        cairo_surface_write_to_png_stream(img_surf, write_cb, &buf);

        cairo_surface_destroy(img_surf);

        *out_is_svg = false;
    } else {
        // Emit SVG
        cairo_surface_t* svg_surf = cairo_svg_surface_create_for_stream(
            write_cb, &buf, w, h);

        cairo_t* svg_cr = cairo_create(svg_surf);
        poppler_page_render_for_printing(page, svg_cr);

        cairo_destroy(svg_cr);
        cairo_surface_destroy(svg_surf);

        *out_is_svg = true;
    }

    g_object_unref(page);

    *out_len = static_cast<int>(buf.size());
    if (*out_len == 0) {
        *out_len    = 0;
        *out_is_svg = false;
        return nullptr;
    }

    unsigned char* out = static_cast<unsigned char*>(std::malloc(buf.size()));
    if (!out) {
        *out_len    = 0;
        *out_is_svg = false;
        return nullptr;
    }

    std::memcpy(out, buf.data(), buf.size());

    return out;
}

Key decisions

  • Single marshalled buffer. The native side allocates one contiguous block so any .NET caller - Mono, CoreCLR, AOT - can copy and free safely.

  • ByteSink is a trivial std::vector<uint8_t> wrapper

    no libpng or gzip is pulled in - Cairo writes PNG/SVG bytes directly.

  • Tolerance for "mixed" pages. If any vector/text survives, keep SVG

    otherwise fall back to PNG. That rule kept our Word files tiny yet visually identical.

Building the shared object / DLL

The repository is set up with CMake + vcpkg:

git clone https://github.com/Forevka/pdf2svgwrapper
cd pdf2svgwrapper
git submodule update --init --recursive   # pulls vcpkg
mkdir build && cd build
cmake .. -DCMAKE_BUILD_TYPE=Release
cmake --build .

This produces pdf2svgwrapper.dll + bunch dependencies (Windows) or libpdf2svgwrapper.so (Linux).

Shipping it to .NET

P/Invoke bindings

Because the native API is pure C, the C# side is a handful of [DllImport] declarations:

static class NativeMethods
{
  [DllImport("native-svg2pdf/pdf2svgwrapper", CallingConvention = CallingConvention.Cdecl)]
  public static extern IntPtr pdf_open_doc(
    IntPtr pdfData,
    int pdfLen,
    out int pageCount
  );

  [DllImport("native-svg2pdf/pdf2svgwrapper", CallingConvention = CallingConvention.Cdecl)]
  public static extern IntPtr pdf_get_page_data(
    IntPtr docHandle,
    int pageNum,
    bool isForcePng,
    int dpi,
    out int dataLen,
    out bool isSvg
  );

  [DllImport("native-svg2pdf/pdf2svgwrapper", CallingConvention = CallingConvention.Cdecl)]
  public static extern void pdf_close_doc(IntPtr docHandle);

  [DllImport("native-svg2pdf/pdf2svgwrapper", CallingConvention = CallingConvention.Cdecl)]
  public static extern void pdf_release_buffer(IntPtr ptr);
}

A thin Pdf2SvgInterop class converts those raw pointers into managed byte[] or MemoryStream.

Explaining Pdf2SvgInterop.ConvertPdfPages

public static IEnumerable<PdfPageData> ConvertPdfPages(byte[] pdfBytes, bool isForceToPng, int dpi = 300)
{
    // pin the managed array
    var handle = GCHandle.Alloc(pdfBytes, GCHandleType.Pinned);
    try
    {
        IntPtr ptr = NativeMethods.pdf_open_doc(handle.AddrOfPinnedObject(), pdfBytes.Length, out int pageCount);
        if (ptr == IntPtr.Zero)
                 throw new PopplerCairoConvertationException("Failed to open PDF.");

        try
        {
            for (int i = 0; i < pageCount; i++)
            {
                IntPtr dataBuf = NativeMethods.pdf_get_page_data(ptr, i, isForceToPng, dpi, out int dataLen, out
                    var isSvg);

                if (dataBuf == IntPtr.Zero) throw new PopplerCairoConvertationException($ "Page {i} conversion failed.");

                try
                {
                    var dataBytes = new byte[dataLen];
                    Marshal.Copy(dataBuf, dataBytes, 0, dataLen);

                    yield return new PdfPageData
                    {
                        Data = new MemoryStream(dataBytes, writable: false),
                        IsSvg = isSvg,
                    };
                }
                finally
                {
                    NativeMethods.pdf_release_buffer(dataBuf);
                }
            }
        }
        finally
        {
            NativeMethods.pdf_close_doc(ptr);
        }
    }
    finally
    {
        handle.Free();
    }
}

Why this shape?

Concern

How the method addresses it

GC pinning

We never hand managed memory to C++; instead C++ allocates, C# copies.

Large PDFs

Because we use generators:
Only one page’s bytes sit on the managed heap at any moment.
try/finally in an iterator runs when the enumerator is disposed, so the native Poppler document cannot leak - even if the consumer breaks out of the foreach.

Thread safety

Each call operates on its own document handle - no global state.

AOT friendliness

Pure [DllImport], no Marshal.StructureToPtr, so the IL linker keeps only what it needs on iOS/Android trims.

Back-pressure

The caller decides when to dispose or stream each PageResult; we don’t hold unmanaged buffers past the loop.

No SafeHandle close-over a try/finally instead - this keeps allocations to a minimum in the hot loop.

Cross-platform lookup is handled by the NuGet’s runtimes/*/native/ layout, so pdf2svgwrapper resolves to pdf2svgwrapper.dll, .so, or .dylib automatically.

NuGet Access

This package can be added to your project via this command

dotnet add package PDF2SVG.PopplerCairo.Bindings

That does three things automatically:

What happens

Managed DLL is referenced (PDF2SVG.PopplerCairo.Bindings.dll)

Gives you the Pdf2SvgInterop class out of the box.

Native binaries are copied to runtimes/*/native/ in obj/bin

The correct pdf2svgwrapper (.dll, .so, or .dylib) lands beside your app at publish time - no extra MSBuild tweaks.

DllImport resolution just works on Windows and Linux.

You can dotnet publish -r win-x64 orlinux-x64and run immediately.

Example of usage

The sample program shows basic usage:

byte[] pdfBytes = File.ReadAllBytes("./input-2.pdf");

var pageData = Pdf2SvgInterop.ConvertPdfPages(pdfBytes, true); // optional dpi can be provided

var index = 0;
foreach (var pdfPageData in pageData)
{
    if (pdfPageData.IsSvg)
        File.WriteAllBytes($"./output-{index}.svg", pdfPageData.Data.ToArray());
    else
    {
        File.WriteAllBytes($"./output-{index}.png", pdfPageData.Data.ToArray());
    }

    Console.WriteLine($"Pdf page {index} processed");
    index++;
}


Console.WriteLine("Pdf processed");

This will read input-2.pdf from the project directory and create output-{index}.svg or output-{index}.png for each page.

Where to Grab the Code

Repository

Native C++ engine - Poppler + Cairo wrapper

https://github.com/Forevka/pdf2svgwrapper

CMake project, minimal C API, vcpkg manifests, ready to cross-compile Windows / Linux

.NET bindings & convenience helpers

https://github.com/Forevka/pdf2svg_poppler_cairo

PDF2SVG.PopplerCairo.Bindings source, P/Invoke layer, sample console app

Published NuGet package

https://www.nuget.org/packages/PDF2SVG.PopplerCairo.Bindings

Pre-built managed DLL plus platform-specific native binaries

End-to-end demo

PDF2SVG.PopplerCairo.Use/Program.cs file (inside the binding repo)

Opens a PDF, streams each page to SVG/PNG in-memory, and drops them into a disk

Conclusion

In under a week I went from "Word reports with blurry screenshots" to a drop-in .NET helper that streams crisp SVG pages straight into Open XML. The recipe was simple:

  1. Leverage battle-tested C libraries (Poppler + Cairo).

  2. Hide them behind a five-function C facade.

  3. Use P/Invoke to light them up in C#.

  4. Pack the native bits so downstream teams just reference a NuGet.

The result feels almost unfair: a few hundred lines of C++, a few dozen lines of C#, and suddenly every .NET app gets a PDF-to-SVG super-power.

So next time you bump into a "native only" library, remember - bridging C/C++ to C# is usually the easy part. The real magic is deciding exactly the problem you want that native code to solve.
